The SIGHTER SC60N DC MCB is a high-quality, compact protection device designed for DC applications such as solar PV arrays, battery storage systems, and other renewable-energy installations. It protects against overloads and short-circuits in DC circuits up to 1000V, ensuring reliable protection for your combiner boxes, inverters, and downstream devices.
Rated Current (In): 6A / 10A / 16A / 20A / 25A / 32A / 40A / 50A / 63A
Breaking Capacity: 6kA (typical for PV DC versions)
Tripping Curve: C-curve for general DC load & PV applications
Mechanical Life: >20,000 operations
Electrical Life: >10,000 operations under load
Mounting: Standard 35mm DIN rail
Terminal Capacity: Up to 25 mm² conductor
Operating Temperature: -40°C to +85°C
Standards: IEC 60947-2, IEC 60898-2 (DC versions)
